6N137 SOIC-8 Digital Output Optocoupler IC
6N137 is a through-hole single-channel high-speed 10MBd optocoupler in an 8-pin SOIC package. This device is mainly used in digital field bus isolation such as microprocessor system interface, PLC, ATE input/output isolation, computer peripheral interface, CC-link, DeviceNet, profibus, SDS, high-speed A/D and D/A conversion, AC plasma. display panel level shifting, multiplexed data transmission, digital control power supply and elimination of ground loop.
Uses
Microprocessor system interface
PLC, ATE input/output isolation
Computer peripheral interface
Digital fieldbus isolation: CC-link, DeviceNet, profibus, SDS
High-speed A/D and D/A conversion
AC plasma display panel level shifting
Multiplexed data transmission
Digital control power supply
Ground loop elimination, noise isolation
| Series |
6N137 |
| Vf - Forward Voltage |
1.4V |
| Vr - Reverse Voltage |
5V |
| Data Rate |
10 Mb/s |
| Number of Channels |
1 Channel
|
| Number of Pins |
8 |
| Package Type |
SOIC-8 |
