BC337 TO92 Transistor
BC337 is an NPN Transistor commonly used in low power amplifier circuits. NPN Bipolar Transistor is designed for use in linear and switching applications. Housed in TO-92 case designed for medium power applications. It is suitable for use with microcontrollers. It is rated at 45V 800mA.
Equivalent Transistors:
2N7051 , BC338, BC487, 2N2222
Uses
- Audio frequency driver stages
- Low power audio amplifiers
- Switch for small loads
- Amplifying low gain signals to high gain
- Darlington pair
| Product Code |
BC337 |
| Transistor Type |
NPN |
| Breakdown Voltage (Max) |
45V |
| Collector Current (Ic) (Max) |
800mA |
| Power - Max |
625mW |
| Package Type |
TO-92 |
