CDRH129 330UH SMD Coil
CDRH129 Power Inductor is a passive electronic device. A ferrite drum and copper wire are wound on it. Also called pad, the terminals of this inductor are designed for surface mounting. Additionally, the inductor has magnetic shielding. Additionally, this inductor has the highest moisture sensitivity level of 1.
Applications Fields
DC-DC converter is used as an inductor in laptops, Gaming Machines, etc.
Technical Specifications:
- Core: Ferrite
- Inductance (μH): 330
- Tolerance (%): 30
- Current Rating (A): 4.48
- at 20℃ DC Resistance (DCR) (mΩ): 35
