Notify me when its in stock| FEATURES | RANGE | BEST ACCURACY | |
| MODEL | UT71A | UT71B | |
| DC VOLTAGE (V) | 200MV / 2V / 20V / 200V / 1000V | ± (0.1 +% 8) | ± (0.05% + 5) |
| AC VOLTAGE (V) | 2V / 20V / 200V / 1000V | ± (0.8 % + 40) | ± (0.6% + 40) |
| DC CURRENT (A) | 200ΜA / 2000ΜA / 20MA / 200MA / 10A | ± (0.2% + 20) | ± (0.15% + 20) |
| 200ΜA / 2000ΜA / 20MA / 200MA / 10A | ± (1 +% 15) | ± (0.8 + 15%) | |
| RESISTANCE (Ω) | 200Ω / 2KΩ / 20KΩ / 200KΩ / PER 2M / 20M< /TD> | ± (0.5% + 20) | ± (0.4% + 20) |
| CAPACITANCE ( F) | 20NF / 200 NF / 2ΜF / 20ΜF / 200ΜF / 2MF / 20MF | ± (1.5% + 20) | ± (1.2%) + 20) |
| FREQUENCY (HZ) | 20HZ-200MHZ | ± (0.1 +% 15) | ± (0.1 + 15%) |
| TEMPERATURE (° C) | -40 ° C ~ 1000 ° C | ± (1 + 30%) | |
| TEMPERATURE (° C) | -40°F ~ 1832°F | ± (1.5% + 50) | |
| IMAGE COUNT | 19999 | 19999 | |
| AUTO RANGE | √ | √ | |
| TRUE RMS | √ | √ | |
| BANDWIDTH (HZ ) | 100KHZ | √ | √ |
| DUTY CYCLE | ~ 90% 10% | ± (1 + 30%) | ± (1 + 30%) |
| DIODE | √ | √ | |
| AUTOMATIC OFF | √ | < TD>√||
| CONTINUITY BUZZER | √ | √ | |
| √ | √ | ||
| RELATIVE MODE | √ | √ | |
| DATALOG | 100 | ||
| USB INTERFACE | √ | √ | |
| DUAL BACKLIGHT | √< /TD> | √ | |
| ANALOG BAR GRAPH | √ | √ | |
| ICON FULL SCREEN | √ | √ | |
| DCV INPUT IMPEDANCE FOR | DC 200MV: SURROUNDINGS 2.5GΩ, ALL OTHER RANGE: 10 MQ | √ | √ |
| 4 - 20MA CYCLE | 0 ~ 100% | ± (1 + 50%) | |
| INSURED 10 A | √ | √ | |
| CURRENT MEASUREMENT ALARM | √ | √ | |
| POWER | 9V BATTERY (6F22) | ||
| LCD SIZE | 73MM AND GRAY | ||
| PRODUCT NET WEIGHT | 384G | ||
| PRODUCT SIZE | 200MM X 93MM X 40MM | ||
