| Features | Range | Best Accuracy | |
| Model | UT60A | UT60B | |
| DC Voltage (V) | < TD class=xl65>400mV / 4V / 40V / 400V / 1000V± (0.8% + 1) | ± (0.8% + 1) | |
| AC Voltage (V) | 4V / 40V / 400V / 750V | ± (% 1 + 5 ) | ± (1% + 5) |
| Communication bandwidth | 40Hz ~ 400Hz | ||
| TD> | √ | √ | |
| DC Current (A) | 400mA / 4000mA / / 40mA 400mA / 4A / 10A | ± (1 +% 2) | ± (1 +% 2) |
| AC Current (A) | 400mA / 4000mA / / 40mA 400mA / 4A / 10A | ± (1.5% + 5 ) | ± (1.5% + 5) |
| Resistance (Ω) | 400Ω / 4kΩ / 40kΩ / 400kΩ / 4MΩ / 40MΩ | ± (1 + 2%) | ± (1 + 2%) | Capacitance (F) | 40nF / 400nF / 4μF / 40μF / 100μF | ± (3% + 5) | < TD class=xl65>± (3% + 5)
| Frequency (Hz) | 10Hz ~ 9MHz | ± (0.1% + 3) | ± (0.1% + 3) |
| Duty Cycle | ~ 99.9% 0.1% | √ | √ |
| Features | |||
| 10A Range with Fuse | Ceramic fuse | √ | √ |
| Relative Mode | √ | √ | |
| Icon Full Screen | √ | √ | |
| Diode | √ | √ | |
| Continuity Buzzer | √ | √ | |
| Low Battery Display | √ | √ | |
| Input Impedance for DC Voltage Measurement | 10 MQ | √ | √ |
| Data Hold | √ | √ | |
| Range Auto | √ | √ | |
| Auto / Manual Range | √ | √ | |
| Display Light | √ | √ | |
| Max Screen | 3999 | √ | √ |
| Auto Power Off | √ | √ | |
| General Characteristic | |||
| Power | 9V Battery (6F22) | ||
| LCD Size | 63mm × 31mm | ||
| Product Color | Red and Gray | ||
| Product Net Weight | 340g | ||
| Product Size | 177mm × 85mm × 40mm | ||
| Standard Accessories | Test Lead, Battery, Test Clip, RS232C Interface Cable, PC Software CD | ||
| Standard Individual Packaging | Gift Box, English Manual | ||
| Standard Carton Measurement | 595mm x 400mm x 326mm (0.078 MBP Per Standard Box) | ||
| Standard Box Gross Weight | 21kg | ||
