| Basic Functions | Range | Best Accuracy |
| DC Voltage | 200mV/2V/20V/200V/1000V | (0.5%+1) |
| AC Voltage | 2V/20V/200V/750V | (0.8%+3) |
| DC Current | 20mA/200mA/20A | (0.8%+1) |
| AC Current | 20mA/200mA/20A | (1%+3) |
| Resistance | 200W/2kW/20kW/200kW/2MW/200MW | (0.8%+1) |
| Capacitance | 20nF/200nF/2mF/100mF | (4%+3) |
| Frequency | 2kHz/20kHz | (1.5%+5) |
| Special Functions | ||
| Diode | ||
| Continuity Buzzer | ||
| Data Hold | ||
| Display Backlight | Auto Sensor | |
| Full Icon Display | ||
| Sleep Mode | ||
| Low Battery Display | ||
| Input Impedance for DC | Around 10MW | |
| Voltage Measurement | ||
| Max. Display | 1999 | |
| GENERAL CHARACTERISTICS | ||
| Power | 9V Battery (6F22) | |
| LCD Size | 59 x 25mm | |
| Product Colour | Red and Grey | |
| Product Net Weight | 275g | |
| Product Size | 165 x 80 x 38.3mm | |
| Standard Accessories | Test Lead, Battery, English Manual, Point Contact Temperature Probe, Test Clip | |
