Esp8266 Based 0.91'' Oled Display 32Mb Development Board

Esp8266 Based 0.91'' Oled Display 32Mb Development Board

 Wifi Kit 8 is a development board that can be programmed with Arduino and NodeMCU, with Esp8266 wifi base, Cp2014 communication. It has a built-in OLED screen with a size of 0.91 inches, wifi, communication port, charge-discharge circuit for lithium batteries.

Wifi Kit 8 Features:

• CP2014 USB to serial chip
• Lithium battery interface and charge-discharge circuit
• 32MByte Flash
• Wifi antenna
• 0.91 inch OLED screen
is
• a cost-effective IoT product of business development program, using ESP8266
• programmable with Arduino and NodeMCU.
• Routes all pins of ESP8266
• 12 digital pins configurable for read, write, IIC, SPI, medium, PWM and other functions
1
• AD input
• Integrated 0.91 inch 128*32 OLED
• Working voltage: 3.3V~7V

 Use with Ardunio and Sample Code
