INA114AP DIP-8 Instrumentation Amplifier IC
INA114 is a low-cost, general-purpose instrumentation amplifier that offers excellent accuracy. Its versatile 3-op amp design and small size make it ideal for a wide variety of applications.
A single external resistor can range anywhere from 1 to 10,000 adjusts the gain. Built-in input protection can withstand up to ±40V without damage. It works with low power supplies down to ±2.25V, allowing use in battery-powered and single 5V supply systems. Quiescent current is maximum 3mA.
Usage Areas
Bridge Amplifier
Thermocouple Amplifier
Rtd Sensor Amplifier
Medical Instrumentation
Data Acquisition
| Series |
INA114AP |
| Supply Voltage |
4.5V - 36V |
| Number of Channels |
1 Channel |
| 3 dB Bandwidth |
10 kHz |
| CMRR |
110 dB |
| Number of Pins |
8 Pin |
| Package Type |
DIP-8 |
