KSD301 110 °C Screwed Limit Thermostat with Reset Button NC 250V 10A
KSD301 110 degree normally closed circuit limit thermostat with screws and reset button. Since this product is a closed circuit, it passes voltage until the temperature reaches 110 degrees, and when it reaches 110 degrees, it cuts off the voltage. It is made of high quality ceramic material.
Unlike other models, screw limit thermostats have a screwed part to fix the mounting holes in place. Its size is M4. There are no bolts in the product.
The product cuts off the electricity flow when the specified temperature is reached in limit thermostats with a reset button. To activate it again, you need to press the reset button on the back.
Features:
- 250V 10A
- NC
- Pentagonal part distance between two opposite surfaces: 16mm
- Length: 21.5mm Excluding connection legs
- Screw part: m4 x 5mm
