LED Rotary Encoder Module
LED Rotary Encoder Module is a module with 4 RGB LEDs that you can use in pulse signal production.
Connection:
- Red: + (turns on the LEDs)
- Black: -
- Yellow: - (When the button on it is pressed, it becomes short-circuited with gray (-).
- Green: Pulse A
- Blue: Pulse B
- Grey: -
- Orange: Led
- Purple: Led
- Brown: Led
