LF412CN DIP-8 OpAmp IC
They are low-cost, high-speed JFET input operational amplifiers with very low input offset voltage and input offset voltage drift. They require low supply current but provide a large gain bandwidth product and fast slew rate. Additionally, well-matched high-voltage JFET input devices provide very low input bias and offset currents. The LF412-N dual is pin compatible with the LM1558, allowing designers to instantly upgrade the overall performance of existing designs.
These amplifiers can be used in high-speed integrators, fast D/A converters, sample and hold circuits, and many circuit applications that require low input offset voltage and drift, low input bias current, high input impedance, high slew rate and wide bandwidth.
Usage Areas
High Speed Integrators
Fast D/A Converters
Sampling and Hold Circuits
| Series | LF412CN |
| Supply Voltage | 7v - 40V |
| Bandwidth | 4Mhz |
| SR - Rotation Speed | 15V/us |
| Number of Channels | 2 Channel |
| Number of Pins | 8 Pin |
| Package Type | DIP-8 |
