LM3524DM SOIC-16 Smps Switching - Control IC
LM3524D is an improved version of the industry standard LM3524. Although it has advanced features and additional features, it is pin for pin compatible with existing 3524 families.
LM3524D has a 5V reference with ±1% accuracy. The current carrying capacity of the output driver transistors was increased to 200 mA while reducing VCEsat and increasing the VCE breakdown to 60V. The common mode voltage range of the error amplifier was increased to 5.5V to eliminate the need for a resistive divider from the 5V reference.
| Series |
LM352X |
| Supply Voltage |
40V |
| Output Voltage |
60V |
| Output Current |
200 mA |
| Number of Exits |
2 Exits
|
| Number of Pins |
16 |
| Package Type |
SOIC-16 |
