LMC7660IMX/NOPB SOIC-8 SMD DC to DC Converter IC
LMC7660 supports a positive voltage from −1.5V to +1.5V to +10V. It is a CMOS voltage converter that can convert −10V to the corresponding negative voltage. The LMC7660 is a pin-by-pin replacement for the industry standard 7660. The converter features: operation over the full temperature and voltage range, low quiescent current and high power efficiency without the need for an external diode.
| Series |
LMC7660IMX |
| Supply Voltage |
1.5-10V |
| Output Voltage |
-1.5V - -10V |
| Output Current |
20 mA |
| Number of Exits |
1 Exit
|
| Number of Pins |
8 |
| Package Type |
SOIC-8 |
