LMD18245 Motor Driver IC TO-222-11
LMD18245 full bridge power amplifier is used to drive current in a brush type DC motor or one phase of a bipolar stepper motor and contains all the circuit blocks needed to control it. The multi-technology process used to build the device combines bipolar and CMOS control and protection circuitry with DMOS power switches on the same monolithic structure. LMD18245 controls the motor current with a constant off-time chopper technique.
Usages
Full, Half and Micro Step Stepper Motor Drivers
Stepper Motor and Brushed DC Motor Servo Drivers
Automatic Factory, Medical and Office Equipment
| Series |
LMD |
| Supply Voltage |
12-55V |
| Operating Supply Current |
8ma |
| Output Current |
3A |
| Number of Exits |
2 Exits
|
| Number of Pins |
11 |
| Package Type |
To-220-11 |
