ADG804YRMZ MSOP-10 Smd Switch IC
ADG804 is a low voltage 4-channel CMOS multiplexer consisting of four single channels. This device offers a resistance of less than 0.8 Ω over the full temperature range. Digital inputs can handle 1.8 V logic with a 2.7 V to 3.6 V supply.
ADG804 connects one of four inputs to a common output, as determined by the 3-bit binary address lines A0, A1, and EN. , switches to D. A Logic 0 on the EN pin disables the device. ADG804 features switching before cutting.
Uses
- MP3 players
- Power routing
- Battery-powered systems
- PCMCIA cards
- Cellular phones
- modems
- Audio and video signal routing
- Communications systems
| Input Voltage | 1.65V - 3.6V |
| Supply Voltage Configuration | Single Feed |
| Number of Channels | 4 |
| Resistance | 650 mOhm |
| Number of Pins | 10 Pin |
| Package Type | MSOP10 |
