ESP-WROOM-32 2.8" 240X320 Resistive Touch Screen Development Board

ESP-WROOM-32 2.8" 240X320 Resistive Touch Screen Development Board

ESP-WROOM-32 2.8" 240X320 Resistive Touch Screen Development Board is becoming more and more popular for DIY projects.

This smart display module adopts a 2.8-inch touch screen and has WiFi and Bluetooth capabilities. It is a true "Internet of Things" development tool for application remote control, remote environmental data collection, remote data fusion and other applications. It supports one-key automatic download and provides LVGL demo examples. It has a dual-core CPU clock frequency of up to 240MHz and can integrate various source peripherals.

Github

Wiki

Features

• Model: ESP32-2432S028-R (For ESP32-D0WDQ6 controller (based on)
• Processor: ESP32WROOM32
• Display: 2.8 inch TFT screen, touch screen
• Resolution: 240*320px
• Processor information: Espressif ESP32 32 bit dual core processor
• Core: ESP32-D0WDQ6
• Antenna integrated into module
• TFT screen with ILI9341 driver
• SD slot up to 4 GB
• Micro-USB socket
• Operating temperature: -20 to + 70 °C
• Supply voltage: 5V, approx. 90 mA
• Weight: approx. 44g
• Module size: approx. 8.6 x 5.4 cm
