PC817 24V 1 Channel Optocoupler Isolation Module. This versatile module uses optocoupler isolation technology to provide reliable signal transmission and immunity from interference, making it ideal for applications where level matching and isolation are critical.

Areas of Use

• Industrial Automation Systems
• Motor Control and Drives
• PLC (Programmable Logic Controller) Interface
• Sensor Signal Conditioning
• Microcontroller Output Level Shifting and Protection

General Features

• Optocoupler Isolation: The module incorporates optocoupler isolation to provide stable and reliable signal transmission by protecting sensitive circuits from electrical noise and interference.
• Versatile Applications: Inductive circuits such as motors Enables level shifting and isolation for driving components, converting voltage levels for PLC inputs (e.g. converting 3V or 5V to 24V), inverter signal inversion, and current amplification.
• High Isolation Voltage: Provides robust protection against voltage spikes and surges by offering isolation voltage greater than 3000V. Efficient and
• Durable Design: Built to withstand a wide temperature range (-55°C to 110°C) and has a maximum application signal frequency of 5KHz, suitable for demanding industrial and automation applications.

Technical Specifications

• Input Signal Voltage: 24V (DC)
• Output Signal Voltage: Wide voltage range suitable for DC loads
• EL817 Features:

  • Isolation Voltage: Greater than 3000V
  • Input Current: Maximum 50mA
  • Operating Current: Greater than 1mA
  • Maximum Output Current: Up to 50mA (suitable input current)
  • Operating Temperature: -55°C to 110°C
  • Maximum Application Signal Frequency: 5KHz
• Dimensions: 40x16x17mm
