PIC12F675 PDIP-8 8-Bit 20Mhz Microcontroller
PIC12F675 is a microcontroller designed for low-end applications and systems. It is good for engineers to learn and try as it has high flash memory rewrite cycle. The controller has 2 KByte flash memory, which is enough for beginners to develop basic programs. Additionally, the 6 GPIO pins are designed to handle a maximum current of 25mA, which meets the threshold of many peripheral devices and sensors.
Uses
Scrolling screen , temperature monitor etc. Low end applications such as
Startup applications
Hobby projects
Imaging units
Development board for students
Technical Specifications
| Product Code |
PIC12F675 |
| Program Memory Type |
Flash |
| Program Memory Size (KB) |
1.7 |
| CPU |
RISC 8-Bit PIC |
| SRAM (B) |
64 |
| Data EEPROM / HEF (bytes) |
128 |
| Timers |
1 x 8 bit, 1 x 16 bit |
| Number of Comparators |
1 |
| Operating Voltage Range (V) |
2 - 5.5V |
| Number of Pins |
8 |
