Out Of Stock
Notify me when its in stockAfter a long wait, Raspberry Pi 5 has finally been released! This mini computing power is a game changer, delivering speed and versatility like never before. It's a revolution in minicomputing, delivering unprecedented speed and a host of new features.
Raspberry Pi 5 with a 64-bit quad-core Arm Cortex-A76 processor running at 2.4 GHz Provides a 2-3x increase in CPU performance compared to Raspberry Pi 4! Raspberry Pi 5 also brings a huge list of great new features and improvements, making it the best Raspberry Pi yet!
The new 64-bit quad-core Arm Cortex-A76 processor at the heart of Raspberry Pi 5 runs at 2.4 GHz with encryption extensions, 512 KB L2 caches per core, and 2 MB shared L3 cache.
This new Broadcom BCM2712 SoC (System on Chip) provides a 2-3x increase in performance over the previous generation Raspberry Pi!
Raspberry Pi 5 delivers a significant increase in graphics performance from the 800MHz VideoCore VII GPU connected to the BCM2712 via PCI Express. It allows the Raspberry Pi 5 to deliver full dual 4Kp60 display output via micro HDMI. These performance improvements provide a smooth desktop experience when browsing the web and streaming video.
For the first time it is a full-size Raspberry Pi computer using Raspberry Pi's in-house manufactured silicon.
The RP1 "south bridge" provides the bulk of the I/O capabilities for the Raspberry Pi 5 and provides a boost in peripheral performance and functionality. provides step change.
RP1 also offers a pair of quad-lane 1.5 Gbps MIPI transceivers, tripling total bandwidth and allowing you to connect any combination of up to two cameras or displays.
This, along with display performance improvements from the redesigned Raspberry Pi Image Signal Processor (ISP), allows you to use your Raspberry Pi with the Raspberry Pi 5 for commercial and industrial applications. It opens up new project opportunities and major improvements for users.
Makers and enthusiasts have been wanting a dedicated onboard power button on the Raspberry Pi for as long as we can remember - and Raspberry Pi 5 finally provides this much-desired convenience!
A real time clock (RTC) built into the motherboard allows you to retain time/date information even when you turn it off or are not connected to the internet (with a backup battery connected). A special header has been added to the board to allow the use of a backup battery for the RTC (battery sold separately). A lithium battery with a compatible head will be available on or shortly after the launch of the Raspberry Pi 5.
Raspberry The Pi 5 includes a new dedicated fan header to the right of the familiar GPIO pin header, allowing you to connect and run a cooling fan without interfering with your GPIO-connected devices. Now you can add HATs and other hardware without workarounds for connecting fans.
Another useful addition to the Raspberry Pi 5 is the custom It is the UART header. Now you can debug your Raspberry Pi 5 and control it without interfering with your GPIO pins.
This dedicated UART header also allows debugging from boot and comes with the Raspberry Pi Debug probe for fast, convenient debugging It is designed to be used.
Processor
Features
