ATMEGA164PA-PU DIP-40 20MHz Microcontroller

Ratings & Reviews (0)
Comment
Brand: Atmel
Product Code: KOM.MKD.02.000043
Stokta son 1 ürün
228.80 TL + VAT
VAT Included: 274.56 TL

ATMEGA164PA-PU DIP-40 20MHz Microcontroller

High performance Microchip picoPower® 8-bit AVR® RISC based microcontroller, 16 KB ISP flash memory, read-write features, 512B EEPROM Combines with 1 KB SRAM, 32 general-purpose I/O lines, 32 general-purpose operating registers, one real-time counter, three flexible timers/counters with comparison modes and PWM, two USARTs, one byte-oriented Two-Wire serial interface, programmable 8-channel 10-bit A/D converter with optional differential input stage with gain, programmable watchdog timer with internal oscillator, SPI serial port, a JTAG (IEEE® 1149.1 compliant) test interface for on-chip debugging and programming, and six software-selectable power savers mode. The device operates between 1.8-5.5 volts. Executing powerful instructions in a single clock cycle, the device achieves throughput approaching one MIPS per MHz by balancing power consumption and processing speed.

Technical Specifications

Poduct Code  ATMEGA164PA-PU
Program Memory Type  Flash
Program Memory Size 16 kB
Bus Width 8-Bit
Max Clock Frequency 20 MHz
Data RAM Size 1 kB
I/O Count 32
Timer/Counter 3
 Operating Voltage Range (V) 1.8 - 5.5V
Number of Pins 40

Weight(Kg)
0.02
