ATMEGA48A-PU DIP-28 20MHz Microcontroller

Ratings & Reviews (0)
Comment
Brand: Atmel
Product Code: KOM.MKD.02.000035
Stokta 10+ ürün
132.00 TL + VAT
VAT Included: 158.40 TL

ATMEGA48A-PU DIP-28 20MHz Microcontroller

High performance Microchip 8-bit AVR® RISC based microcontroller, 4 KB ISP Flash memory, 256B EEPROM, 512B SRAM, 23 general purpose I/O line, 32 general-purpose operating registers, combines three flexible timer/counter and comparison modes, internal and external interrupts, serial programmable USART, byte-oriented Two-Wire serial interface, SPI serial port, 6-channel 10-bit A/ D converter (8 channels in TQFP and QFN/MLF packages), programmable watchdog timer internal oscillator and five software-selectable power saving modes. The device operates between 1.8-5.5 volts. Executing powerful instructions in a single clock cycle, the device achieves throughput approaching one MIPS per MHz by balancing power consumption and processing speed.

Technical Specifications

Poduct Code  ATMEGA48A-PU
Program Memory Type  Flash
Program Memory Size 4 kB
Bus Width 8-Bit
Max Clock Frequency 20 MHz
Data RAM Size 512 B
I/O Count 23
Timer/Counter 3
 Operating Voltage Range (V) 1.8 - 5.5V
Number of Pins 28

Weight(Kg)
0.02
