ATMEGA48V-10PU DIP-28 10MHz Microcontroller

Ratings & Reviews (0)
Comment
Brand: Atmel
Product Code: KOM.MKD.02.000032
Stokta 10+ ürün
123.20 TL + VAT
VAT Included: 147.84 TL

ATMEGA48V-10PU DIP-28 10MHz Microcontroller

High performance Microchip 8-bit AVR® RISC based picoPower® microcontroller, 4 KB ISP Flash memory, 256B EEPROM, 512B SRAM, Incorporates 23 general-purpose I/O lines, 32 general-purpose operating registers, three flexible timer/counter with comparative modes, internal and external interrupts, serial programmable USART, byte-oriented Two-Wire serial interface, SPI serial port, 6-channel 10-bit A /D converter (8-channel in TQFP and QFN/MLF packages), programmable watchdog internal oscillator timer, and five software-selectable power-saving modes. The device operates between 1.8-5.5 volts. Executing powerful instructions in a single clock cycle, the device achieves throughput approaching one MIPS per MHz by balancing power consumption and processing speed.

Technical Specifications

Poduct Code  ATMEGA48V-10PU
Program Memory Type  Flash
Program Memory Size 4 kB
Bus Width 8-Bit
Max Clock Frequency 10 MHz
Data RAM Size 512 B
I/O Count 23
Timer/Counter 3
 Operating Voltage Range (V) 1.8 - 5.5V
Number of Pins 28

Weight(Kg)
0.02
