IRF2807 - 75V 82A Mosfet - TO220
Power MOSFET uses the latest processing techniques to deliver extremely low resistance per silicon area. Additional features of this design are 175°C junction operating temperature, fast switching speed and improved repeat avalanche rate. These features combine to make this design an extremely efficient and reliable device for use in a wide variety of other applications.
The TO-220 package contains approximately 50 It is universally preferred for all commercial industrial applications at power distribution levels up to 2000 watts. TO-220's low thermal resistance and low package cost contribute to its wide acceptance throughout the industry.
| Series |
IRF2807 |
| Vdss |
75V |
| Id |
82A |
| Strength |
200W |
| Rds(on) |
13mΩ |
| Package Type |
TO-220 |
