MAX3485EESA+ SOIC-8 RS Serial Protocol Integrated
The MAX3485EESA+ is a low power, slew rate limited True Transceiver for RS-485/RS-422 communications. Each device contains a driver and a receiver. The MAX3485EESA+ features slew-rate limited drivers that minimize EMI and reduce reflections caused by improperly terminated cables, allowing for error-free data transmission at data rates up to 12 Mbps. All devices feature advanced electrostatic discharge (ESD) protection. All transmitter outputs and receiver inputs are protected to ±15kV using IEC 1000-4-2 air gap discharge, ±8kV using IEC 1000-4-2 contact discharge, and ±15kV using the human body model.
Usage Areas
● Telecommunications
● Industrial Controlled Local Area Networks
● Transceivers for EMI Sensitive Applications
● Integrated Services Digital Networks
| Series |
MAX3485EESA |
| Supply Voltage |
3-3.6V |
| Data Rate |
12 Mb/s |
| Number of Drives |
1 Drive |
| Number of Recipients |
1 Recipient |
| Number of Pins |
8 |
| Package Type |
SOIC-8 |
