PIC16F628A DIP18 8-Bit 20MHz Microcontroller
Powerful (200 nanoseconds instruction execution), easy to program (only 35 single-word instructions) CMOS Flash-based 8-bit microcontroller packs Microchip's powerful PIC® MCU architecture into an 18-pin package. The IC16F628A features a 4MHz internal oscillator, 128 bytes of EEPROM data memory, a capture/compare/PWM, a USART, 2 Comparators, and a programmable voltage reference ideal for analog/integrated level applications in automotive, industrial, white goods, and consumer applications.
Technical Specifications
| Product Code |
PIC 16F676 |
| Program Memory Type |
Flash |
| Program Memory Size (KB) |
3.5 |
| CPU Speed (MIPS / DMIPS) |
5 |
| SRAM ( KB) |
224 |
| Data EEPROM /HEF (byte) |
128 |
| Timers |
2 x 8 bit, 1 x 16 bit |
| Number of Comparators |
2 |
| Operating Voltage Range (V) |
2 - 5.5V |
| Number of Pins |
18 |
