PIC16F676 DIP14 8-Bit 20MHz Microcontroller
Powerful (200 nanoseconds instruction execution), easy to program (only 35 single word instructions) CMOS Flash-based 8-bit microcontroller packs Microchip's powerful PIC® MCU architecture into a 14-pin package and features 8 channels for 10 channels. It has a 10-bit Analog-Digital (A/D) converter, 1 comparator and 128 bytes EEPROM data memory. Easily adapted for automotive, industrial, appliance and consumer entry-level product applications requiring field reprogrammability.
Technical Specifications
| Product Code |
PIC 16F676 |
| Program Memory Type |
Flash |
| Program Memory Size (KB) |
1.75 |
| CPU Speed (MIPS / DMIPS) |
5 |
| SRAM ( KB) |
64 |
| Data EEPROM /HEF (byte) |
128 |
| Timers |
1 x 8 bit, 1 x 16 bit |
| ADC Input |
8 channels, 10 bit |
| Operating Voltage Range (V) |
2 - 5.5V |
| Number of Pins |
14 |
