Tower Pro SG90S is an ideal servo motor for your small mechanisms. You can use it in your RC vehicles. You can easily use it in your own robot projects with the PWM signal you can receive from the microcontroller.
The gearbox is plastic. It is shipped with servo horns and other parts. As with other hobby servos, the gears can be broken by turning the motor shaft left and right by hand, such manual intervention in the motor should be avoided.
Technical Details:
| Size: |
22.8mm x 12.2mm x 28.5mm |
| Weight: |
13.4 gr |
| Speed |
0.1s / 60degrees (4.8v) |
| 0.08s / 60degrees (6v) |
| Stress Torque |
1.8kg/cm(4.8V )2.2kg /cm(6V) |
| Cable Length: |
175mm |
