74HC14 SMD Integrated
74HC14 decodes two binary weighted address inputs (nA0, nA1) into four mutually exclusive outputs (nY0 - nY3). Each decoder has an enable input (nE). When NE is HIGH, all outputs are forced HIGH. The Enable input can be used as data input for 1 to 4 demultiplexer applications. Inputs include clamp diodes. This enables the use of current limiting resistors to interface the inputs to voltages above VCC.
Uses
-
Memory decoding or data forwarding
-
| Series |
74HC |
| Supply voltage |
2-6V |
| Number of Input Lines |
4 |
| Number of Output Lines |
8 |
| Number of Pins |
16 |
| Package Type |
SMD |
