DAC7611U SOIC-8 Smd Digital Analog Converter Integrated
DAC7611 is a 12-bit digital-to-analog converter (DAC) with guaranteed 12-bit monotonicity performance over the industrial temperature range. It requires a single +5V supply and includes an input shift register, latch, 2.435V reference, DAC and high-speed rail-to-rail output amplifier. For a full scale step the output will settle to 1 LSB within 7µs. The device consumes 2.5mW (0.5mA at 5V).
Usage Areas
Process Control
Data Collection Systems
Closed Loop Servo-Control
Pc Peripherals
Portable Instrumentation
| Series |
DAC7611U |
| Supply Voltage |
4.75V - 5.25V |
| Interface Type |
3-Wire |
| Number of Channels |
1 Channel |
| Resolution |
12 Bit |
| Number of Pins |
8 Pin |
| Package Type |
SOIC-8 |
