HLK-7688A Openwrt Router WIFI Development Kit
HLK-7688A Openwrt Router WIFI Development Kit, based on MT7688AN, developed by Hi-Link It is a development kit with a low-cost and low-power IoT module. The built-in module supports Linux, OpenWRT operating system and custom development. With its rich interface and powerful processor, smart devices and cloud services are widely used.
Kit Content
- HLK-7688A module
- 1x Adapter
- 1x Antenna
- 1x Sma to Ipex converter cable
Features
- Processor: MT7628AN
- Kernel: MIPS24KEc
- RAM: DDR 128MB
- Flash: 32MB
- Frequency : 580MHz
- 150Mbps
- 802.11b/g/n support
- 20/40 channel bandwidth
- AP,STA and AP,STA support
- Interface: SPI/SD-XC/eMMC
- Peripheral Interface: SPI,I2C,I2S,PCM,UART,JTAG,GPIO
- Linux, OpenWRT support
- 5 10/100M ethernet ports
Module Pinout
Diagram
