MAX232DRG4 SOIC-16 SMD RS Serial Protocol Integrated
The MAX232 device is a dual driver/receiver incorporating a capacitive voltage generator to provide TIA/EIA-232-F voltage levels from a single 5-V source. Each receiver converts TIA/EIA-232-F inputs to 5-V TTL/CMOS levels. These receivers have a typical threshold of 1.3 V, a typical hysteresis of 0.5 V, and can accept ±30-V inputs. Each driver converts TTL/CMOS input levels to TIA/EIA-232-F levels.
Usage Areas
● TIA/EIA-232-F
● Battery Operated Systems
● Modems
● Computers
● Terminals
| Series |
MAX232DRG4 |
| Supply Voltage |
4.5-5.5V |
| Data Rate |
120 kb/s |
| Number of Recipients |
2 Recipients |
| Number of Drives |
2 Drive |
| Number of Pins |
16 |
| Package Type |
SOIC-16 |
