MCP6002T-I/MS MSOP-8 Smd OpAmp Integrated
MCP6002T-I/MS is an Operational Amplifier specifically designed for general purpose applications. This family has a 1MHz Gain Bandwidth Product (GBWP) and 90° phase margin (typical). It also maintains a 45° phase margin (typical) with a 500pF capacitive load. This family operates from a single supply voltage as low as 1.8V while drawing 100µA (typical) quiescent current. Additionally, the MCP6002 supports rail-to-rail input and output swing with a common-mode input voltage range of VDD +300mV to VSS - 300mV. This family of op amps is designed with Microchip's advanced CMOS process. The MCP6002 family is available in industrial and extended temperature ranges with a 1.8 to 6.0V power supply range.
Series |
MCP6002T |
Supply Voltage |
1.8V - 5.5V |
Bandwidth |
1 MHz |
SR - Rotation Speed |
600 mV/us |
Number of Channels |
2 Channel |
Number of Pins |
8 |
Package Type |
MSOP-8 |
