Industrial Isolated USB to 4 Channel RS232/485 Converter

Industrial Isolated USB to 4 Channel RS232/485 Converter

Industrial Isolated USB to 4 Channel RS232/485 Converter is an industrial isolated USB to RS232/485 converter, adopting original FT4232HL chip, with protection circuits such as power isolation, internal power isolation, ADI magnetic isolation and TVS, and aluminum alloy case design. It is easy to use with zero-delay fully automatic transceiver circuit, and has the features of fast communication speed, stability, reliability and security, which is suitable for industrial devices and applications with high communication requirements.

For detailed information, you can visit  wiki page.

Features

• Adopts original FT4232HL chip, communicates quickly, is stable and reliable, better compatible.
• SKU: 26681
• Supports USB to RS232, USB to RS485.
• Built-in single-body power supply isolation, provides stable isolated voltage, and does not need extra power supply for isolated terminal.
• Built-in single-body digital isolation, provides signal isolation, high reliability, strong anti-interference and low power consumption.
• Built-in TVS (Transient Voltage Suppressor) effectively suppresses surge voltage and transient surge in the circuit, provides lightning resistance and ESD protection.
• Built-in self-recovery fuse and protection diodes ensure current/voltage stable output, provide over-current/over-voltage resistance and enhance shock resistance performance.
• Built-in 120ohm resistor on RS485 output interfaces, and users can activate it via a DIP switch, easy and flexible.
• 9 LEDs to indicate power, debug status and transceiver status. Industrial grade metal case, suitable for wall mounting and rail mounting, sturdy and beautiful, easy to install.
