ST3PA-B AC 380V Delayed Time Relay - 10S
ST3PA-B AC 380V Delayed Time Relay - 10S. It is a delayed time relay that can be adjusted between 0 and 10 seconds. It is analog adjustable. You can adjust it with the potentiometer on it.
Adjustments such as delay or NO-NC contact are provided through the connection. The product has 8 pins. Delay time or no-nc contact can be adjusted with different connections on 8 pins.
Visual Representation. The relay with the time setting in the product title will be sent.
Technical Specifications
- Model: ST3PA-B
- Adjustable Time: 0-10S
- Working Voltage: 380V AC
- Working Mode: On-Delay
- Nominal Current: 5A
- Dimensions: 40x50x59mm
Connection
.png)
