Industrial 4 Channel RS485 to RJ45 Ethernet Module

Industrial 4 Channel RS485 to RJ45 Ethernet Module

Industrial 4 Channel RS485 to RJ45 Ethernet Module is a multi-functional device data collector/IoT gateway with 4 channel RS485 and one Ethernet port, small size, easy to install and cost-effective. It is suitable for applications such as data collection, IoT gateway, security and safety IoT and smart device monitoring, and meets various application scenarios.

Manual

Features

• Power Options: 6 ~ 45V DC
• SKU: 26360
• Communication Interface: 4 RS485 Ports, 1 Ethernet Port
• Isolation Protection: Power and signal isolation
• Ethernet: RJ45
• Serial Port: Isolated RS485
• Baudrate: 300 ~ 115200bps
• Parity Bit: none, odd, even, mark, space
• Data Bit: 5 ~ 9 bit
• Protocol: ETHERNET, IP, TCP, UDP, HTTP, ARP, ICMP, DHCP, DNS
• Communication Method: TCP/IP, VCOM
• Working Modes: TCP server, TCP client, UDP, UDP multicast
• Working Temperature Range: -40 ~ 85°C
• Dimensions: 91×64.5×24.2mm
